CNC Trainer Spin Train Manufacturer,Supplier and Exporter
Product Code : SEL-CTM-11605
Quick Answer: Designed for learning CNC turning, the CNC Trainer Spin Train turns work up to 100 mm in diameter and 170 mm long, with 300 mm between centres and an 8-station turret.
Last updated: October 2026
Key Features
- Turning diameter 100 mm, turning length 170 mm
- 300 mm between centres, 200 mm swing over
- 8-station turret
- Stroke X 150 mm, Z 200 mm
- CNC system with axis motors and drives, coolant and lubrication systems as standard
- Chip collector with chip bin; spindle with induction or servo motor
Technical Specifications
| Specification | Value |
|---|---|
| Turning length | 170 mm |
| Turning diameter | 100 mm |
| Between centres | 300 mm |
| Stroke X / Z | 150 / 200 mm |
| Job holding | 150 mm |
| Swing over | 200 mm |
| Turret | 8 station |
| Standard accessories | CNC system with axis motors and drives, coolant system, lubrication system, chip collector with chip bin, spindle with induction/servo motor |
About This Product
Built as a learning machine, the Spin Train comes with its CNC system, axis motors and drives, coolant and lubrication systems and a chip collector with bin as standard. Optional additions include an automatic tool changer, CAD/CAM software, a chip conveyor, a voltage stabiliser, an air compressor, coolant through spindle and multiple user licences for training software, so a lab can extend the set-up as its courses develop.
Frequently Asked Questions
What size of work can the Spin Train turn?
Up to 100 mm in diameter and 170 mm in length, with 300 mm between centres, 200 mm swing over and 150 mm job holding.
What comes as standard and what is optional?
Standard items are the CNC system with axis motors and drives, coolant and lubrication systems, a chip collector with bin and a spindle with induction or servo motor. Options include an automatic tool changer, CAD/CAM software, tooling, fixtures or pallets, a chip conveyor, a panel air conditioner and coolant through spindle.
Related: CNC Trainer Machine, CNC Lathe Trainer Stepper, CNC Lathe System, CNC Lathe Machine Floor Model.
For a quotation on the CNC Trainer Spin Train, contact School Educational Instrument.
