CNC Trainer Milling Machine Manufacturer,Supplier and Exporter
.jpg)
Product Code : SEL-CTM-11600
Quick Answer: Aimed at college training, toolroom machine shops and die makers, the CNC Trainer Milling Machine has a 200 x 600 mm table, a 3 HP spindle at 80–4000 rpm and a PC-based CNC controller.
Last updated: October 2026
Key Features
- Table 200 x 600 mm, max. load 100 kg
- Traverses X 400 mm, Y 150 mm, Z 300 mm
- Spindle 80–4000 rpm, max. power 3 HP
- Cutting feed up to 4000 mm/min; rapid feed 2 m/min on each axis
- PC-based CNC controller with graphical simulation
- USB disk compatible; PC interface through RS232
Technical Specifications
| Specification | Value |
|---|---|
| Table size | 200 x 600 mm |
| Max. load on table | 100 kg |
| Traverse X / Y / Z | 400 / 150 / 300 mm |
| Table to spindle face | 200 mm |
| Cutting feed rate | Up to 4000 mm/min |
| Rapid feed X / Y / Z | 2 / 2 / 2 m/min |
| Spindle speed | 80–4000 rpm |
| Spindle power | 3 HP max. |
| Tool changing | Single tool, manual |
| Control system | PC-based CNC controller |
| Codes | G, M, T, F, I, S, J, K |
| Inputs / outputs | 4 sets of high-speed input, 1 set of analogue output signal |
| Modes and interfaces | Master / slave mode; USB disk; RS232 link to PC |
| Connected load | 5 kVA |
| Power supply | 415 V, 50 Hz, 3 phase |
About This Product
Students program this trainer mill with G, M, T, F, I, S, J and K codes, and the controller offers graphical simulation of programs. Tools are changed by hand, one at a time, through a manual tool changing system. The machine runs on a 415 V, 50 Hz three-phase supply with a total connected load of 5 kVA, so the training workshop needs a three-phase connection. The CNC Trainer Milling Machine can be packed for export to Bosnia and Herzegovina, Ecuador, Japan, Grenada, Suriname and Mali.
Frequently Asked Questions
What power supply does the trainer mill need?
A 415 V, 50 Hz, 3 phase supply, with a total connected load of 5 kVA.
Which programming codes does the controller use?
It works with G, M, T, F, I, S, J and K codes, and offers graphical simulation, master/slave mode, USB disk compatibility and an RS232 interface with a PC.
Does it have an automatic tool changer?
No. It uses a single tool with a manual tool changing system.
Related: CNC Trainer Machine, CNC Milling Machine Floor Model, CNC Milling Controller, Smart Mill 600.
For a quotation on the CNC Trainer Milling Machine, contact School Educational Instrument.
