CNC Milling Machine Table Model Manufacturer,Supplier and Exporter
Product Code : SEL-CTM-11596
Quick Answer: As the table version in this CNC milling range, the CNC Milling Machine Table Model has a 400 x 145 mm worktable, a 500 W spindle running at 100–7000 rpm and a 10 mm drilling capacity.
Last updated: October 2026
Key Features
- 500 W spindle motor, 100–7000 rpm
- Worktable 400 x 145 mm with 3 T-slots of 8 mm
- Travel X 260 mm, Y 110 mm, Z 180 mm
- Drilling capacity 10 mm (3/8 in)
- Worktable load up to 20 kg
- Position precision 0.015 mm
Technical Specifications
| Specification | Value |
|---|---|
| Drilling capacity | 10 mm (3/8 in) |
| Worktable size | 400 x 145 mm |
| T-slots | 3, 8 mm |
| Max. worktable load | 20 kg |
| Travel X / Y / Z | 260 / 110 / 180 mm |
| Throat | 150 mm |
| Feed motors | X 1.35 Nm, Y 1.35 Nm, Z 2.2 Nm |
| Max. moving speed X/Y/Z | 2 m/min |
| Feeding speed X/Y/Z | 500 mm/min |
| Position precision | 0.015 mm |
| Spindle speed | 100–7000 rpm |
| Spindle motor | 500 W |
| Machine size (L x W x H) | 1040 x 860 x 940 mm |
| Gross / net weight | 218 / 178 kg |
About This Product
This table model brings programmed milling into a training lab with a smaller footprint than the floor version, measuring 1040 x 860 x 940 mm and weighing 178 kg net. Its spindle has a higher top speed of 7000 rpm, while each axis moves at up to 2 m/min. Students use it for CNC milling and drilling practice in engineering and vocational courses.
Frequently Asked Questions
What spindle does the table model use?
A 500 W spindle motor with a speed range of 100–7000 rpm. The drilling capacity is 10 mm (3/8 in).
What size is the worktable?
The worktable is 400 x 145 mm with 3 T-slots of 8 mm, and it takes a maximum load of 20 kg.
Related: CNC Trainer Machine, CNC Milling Machine Floor Model, CNC Lathe Machine Table, CNC Micro Mill.
For a quotation on the CNC Milling Machine Table Model, contact School Educational Instrument.
