CNC Lathe Machine Floor Model Manufacturer,Supplier and Exporter
Product Code : SEL-CTM-11597
Quick Answer: For CNC turning practice, the CNC Lathe Machine Floor Model offers a 250 mm swing over bed, 450 mm between centres and a 4-station tool turret, driven by a 1 kW main motor at 100–3000 rpm.
Last updated: October 2026
Key Features
- Swing over bed 250 mm, swing over carriage 110 mm
- 450 mm centre distance, 135 mm bed width
- 4-station tool turret with 360 degree turret angle
- 1 kW main motor, spindle 100–3000 rpm
- Travel X 180 mm, Z 320 mm
- Positioning precision 0.015 mm, repeat positioning 0.01 mm
Technical Specifications
| Specification | Value |
|---|---|
| Swing over bed | 250 mm |
| Swing over carriage | 110 mm |
| Centre distance | 450 mm |
| Bed width | 135 mm |
| X / Z axis max. travel | 180 / 320 mm |
| Tailstock travel | 50 mm |
| Tool turret | 4 station, 360 degree |
| Turret return orientation precision | 0.005 mm |
| Positioning precision | 0.015 mm |
| Repeat positioning precision | 0.01 mm |
| X/Z axis motor | 4 Nm |
| Max. moving speed X/Z | 2 m/min |
| Feeding speed X/Z | 500 mm/min |
| Main motor | 1 kW |
| Spindle speed | 100–3000 rpm |
| Machine size (L x W x H) | 1460 x 760 x 1450 mm |
| Packing size (L x W x H) | 1630 x 1070 x 1685 mm |
| Gross / net weight | 530 / 440 kg |
About This Product
A CNC lathe turns round work under program control, with the turret and slides moving on the X and Z axes instead of by handwheel. This floor model weighs 440 kg net and combines a 135 mm wide bed, a 4-station turret with a 360 degree turret angle and a tailstock with 50 mm travel. It is intended for CNC turning instruction in engineering and vocational training workshops.
Frequently Asked Questions
What size of work can the lathe turn?
Swing over bed is 250 mm and swing over carriage 110 mm, with 450 mm between centres. X-axis travel is 180 mm and Z-axis travel 320 mm.
How many tools does the turret hold?
The tool turret has 4 stations and a turret angle of 360 degrees, with a turret return orientation precision of 0.005 mm.
Related: CNC Trainer Machine, CNC Lathe Machine Table, CNC Milling Machine Floor Model, CNC Lathe Controller.
For a quotation on the CNC Lathe Machine Floor Model, contact School Educational Instrument.
