CNC Milling Controller Manufacturer,Supplier and Exporter
Product Code : SEL-CTM-11604
Quick Answer: Controlling up to 6 stepper or servo motors with 6-axis interpolation, the CNC Milling Controller adds an independent servo spindle, G code track preview and 56 input with 48 output ports.
Last updated: October 2026
Key Features
- 6-axis movement with 6-axis interpolation linkage
- Controls 6 stepper or servo motors plus an independent servo spindle
- 56 input and 48 output ports
- 256M built-in electronic disk, expandable to 8G
- USB, Ethernet, serial, U disk and SD card operation
- G code track preview, real-time tracking and syntax check
Technical Specifications
| Specification | Value |
|---|---|
| Axes | 6-axis movement, 6-axis interpolation linkage |
| Motor control | 6 stepper / servo motors |
| Spindle | Independent servo spindle |
| Pulse frequency | Up to 1M |
| Storage | 256M built-in electronic disk, expandable to 8G |
| I/O ports | 56 input, 48 output |
| Analogue output | 2-channel 0–10 V |
| PWM | One set of PWM analogue control port |
| Communication | USB, Ethernet, serial, U disk, SD card |
| Tool magazine support | Straight-line magazine, disc magazine, cylinder tool change |
| System functions | Self-diagnosis, parameter backup and recovery, MPG running of G code, speed look-ahead for smooth transitions |
About This Product
Before a job runs, this controller can preview the G code tool track and check its syntax, and while it runs it tracks the program in real time. Speed look-ahead processing smooths the transition between moves, and the system diagnoses itself and backs up its parameters. Applications for the controller include metal parts processing, flexible processing lines for milling, grinding and polishing, glass panel processing and wooden furniture and handicraft work.
Frequently Asked Questions
How many axes can the CNC Milling Controller run?
It provides 6-axis movement with 6-axis interpolation linkage and controls 6 stepper or servo motors, plus an independent servo spindle.
How are programs transferred to the controller?
It supports USB, Ethernet and serial communication as well as U disk and SD card operation. The built-in electronic disk is 256M, with support for 8G storage expansion.
Which tool magazines does it support?
Straight-line magazines, disc magazines and cylinder tool change.
