Universal Milling Machine Manufacturer,Supplier and Exporter
Product Code : SEL-MMTM-11815
Quick Answer: With a 1150 x 255 mm table that swivels through 22 degrees, the Universal Milling Machine offers 4 spindle speeds from 110 to 580 rpm on a 25.4 mm milling arbor, driven by a 2 HP main motor.
Last updated: October 2026
Key Features
- Table working surface 1150 x 255 mm, 3 T-slots at 57 mm spacing
- Table angular swivel 22 degrees
- Longitudinal feed 600 mm (hand and auto); cross feed 200 mm and vertical feed 400 mm by hand
- 4 spindle speeds, 110 to 580 rpm; 25.4 mm milling arbor
- 2 HP, 1440 rpm main motor; 0.11 kW coolant motor
- Approx. weight 950 kg; floor space 600 x 900 mm
Technical Specifications
| Specification | Value |
|---|---|
| Table working surface | 1150 x 255 mm |
| T-slots | 3, 57 mm apart |
| Table angular swivel | 22 deg |
| Max. spindle centre to table | 400 mm |
| Cross feed (by hand) | 200 mm |
| Longitudinal feed (hand and auto) | 600 mm |
| Vertical feed (by hand) | 400 mm |
| Milling arbor diameter | 25.4 mm |
| Spindle speeds | 4, 110 to 580 rpm |
| Overarm to spindle centre | 140 mm |
| Longitudinal feeds | 3 |
| Coolant motor | 0.11 kW, 2700 rpm |
| Main motor | 2 HP, 1440 rpm |
| Floor space | 600 x 900 mm |
| Height | 1400 mm |
| Weight | Approx. 950 kg |
About This Product
On a universal milling machine the table can be swivelled as well as moved along, across and up and down, so work can be set at an angle to the cutter. Here the longitudinal feed works by hand or automatically over 600 mm with 3 feed rates, while cross and vertical movements are by hand. A 0.11 kW coolant motor is fitted, and the machine weighs approx. 950 kg on a 600 x 900 mm footprint.
Frequently Asked Questions
Which feeds are automatic?
The longitudinal feed works by hand and auto over 600 mm, with 3 longitudinal feeds. Cross feed (200 mm) and vertical feed (400 mm) are by hand.
What spindle speeds does it have?
4 speeds from 110 to 580 rpm, driven by a 2 HP, 1440 rpm main motor, with a 25.4 mm milling arbor.
