Student Medical Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10863
Quick Answer: This medical-pattern student microscope has an aluminium die-cast stand, a quadruple nosepiece with achromatic 10X, 40XSL and 100XSL oil immersion objectives, and a detachable graduated mechanical stage of 120 X 120 mm.
Last updated: October 2026
Key Features
- Stable, robust stand assembled from aluminium die-cast parts
- Quadruple nosepiece with accurate centring and positive click stops
- Achromatic objectives 10X, 40XSL and 100XSL oil immersion
- Detachable graduated mechanical stage, 120 X 120 mm, slide manipulation up to 45 x 75mm
- Plano-concave 50mm adjustable mirror on gimbal mount, interchangeable with sub-stage illumination
- Eyepieces Huygenian 10X-15X or WF 10X
Technical Specifications
| Specification | Value |
|---|---|
| Stand | Aluminium die-cast parts |
| Nosepiece | Quadruple, positive click stops |
| Objectives | Achromatic 10X, 40XSL, 100XSL oil immersion |
| Stage | Detachable graduated mechanical stage, 120 X 120 mm |
| Slide manipulation | Up to 45 x 75mm |
| Illumination | Plano-concave 50mm adjustable mirror on gimbal mount; interchangeable with sub-stage illumination |
| Eyepieces | Huygenian 10X-15X or WF 10X |
About This Product
With a 100XSL oil-immersion objective and a mechanical stage, this student microscope is suited to higher-power slide work, and its stable, robust stand is assembled from aluminium die-cast parts. The graduated stage lets a learner note the position of a field and return to it, and the 50mm mirror on its gimbal mount is interchangeable with sub-stage illumination. It suits uses from elementary education to college level.
Frequently Asked Questions
Which objectives does it have?
Three achromatic objectives on a quadruple nosepiece: 10X, 40XSL and 100XSL oil immersion, used with Huygenian 10X-15X or WF 10X eyepieces.
Can the mirror be replaced with a lamp?
Yes. The 50mm plano-concave mirror on a gimbal mount is interchangeable with sub-stage illumination.
Related: Microscopes, Pathological and Medical Microscope, Student Compound Microscope, Mechanical Stage.
For a quotation on the Student Medical Microscope, contact School Educational Instrument.
