Mechanical Stage Manufacturer,Supplier and Exporter
Product Code : SEL-M-10854
Quick Answer: A mechanical stage moves a slide with control knobs instead of by hand; this full-floating, double-layered unit gives smooth X-Y travel of 100mm by 100mm through coaxial ergonomic knobs, with graduated markings for easy reference.
Last updated: October 2026
Key Features
Full-floating, double-layered mechanical stage
Coaxial ergonomic adjustment knobs
Smooth X-Y axis travel of 100mm by 100mm
Graduated markings for easy reference
Precision-machined components
Technical Specifications
Specification
Value
Type
Full-floating, double-layered
Controls
Coaxial adjustment knobs
X-Y travel
100mm by 100mm
Scales
Graduated markings
About This Product
Moving a slide by hand at higher powers is hard to control, so a mechanical stage holds and moves it with knobs instead. Turning the coaxial ergonomic knobs moves the slide smoothly along the X and Y axes, and the graduated markings let a pupil note where a feature was found and return to it later. The precision-machined, double-layered design suits practical work in school and college labs. Schools and distributors in Uzbekistan, Cabo Verde, Bolivia, the Maldives, Samoa and Lebanon can order the Mechanical Stage from School Educational Instrument.
Frequently Asked Questions
How far does the stage move the slide?
It gives smooth X-Y axis travel of 100mm by 100mm, controlled by coaxial adjustment knobs.
Why are graduated markings useful?
The markings let the user record the X and Y position of a feature on the slide so it can be found again quickly.
