Digital Trinocular Microscope With LED Illumination Manufacturer,Supplier and Exporter
Product Code : SEL-M-10902
Quick Answer: A trinocular port on this LED microscope takes the 3.0 megapixel digital eyepiece camera through the included C-mount relay lens, so images at 40x to 1000x can be broadcast over USB 2.0 in senior high school and college classes.
Last updated: October 2026
Key Features
- 30° inclined trinocular head rotating 360°, interpupillary distance 54 mm to 76 mm
- Four magnification levels from 40x to 1000x
- Reversed ball-bearing quadruple nosepiece with four DIN achromatic objectives, parfocal, parcentred and colour-coded
- 3.0 megapixel digital eyepiece camera, C-mount relay lens, USB 2.0 and imaging software
- Low-mounted coaxial coarse and fine focusing with slip clutch
- Built-in low-profile, ball-bearing mechanical stage; LED illumination with intensity control
Technical Specifications
| Specification | Value |
|---|---|
| Head | Trinocular, 30° inclined, 360° rotation |
| Interpupillary distance | 54 mm to 76 mm |
| Magnification | 40x to 1000x, four levels |
| Nosepiece | Reversed quadruple, ball bearing |
| Objectives | Four DIN achromatic, parfocal, parcentred, colour-coded |
| Camera | 3.0 megapixel digital eyepiece camera, C-mount relay lens |
| Connection | USB 2.0 plug-and-play, imaging software |
| Focusing | Coaxial coarse and fine, low-mounted, slip clutch |
| Stage | Built-in mechanical, low-profile, ball-bearing |
| Illumination | LED with intensity control |
About This Product
The third port means a camera can stay attached while the binocular eyepieces remain free, so a lecturer can broadcast a slide and still look at it directly. The port can also deliver the image to an LCD screen. Low-mounted coaxial focusing knobs give stable adjustment, and the head turns 360° for reverse-position viewing, allowing observation by two people across a bench.
Frequently Asked Questions
Which camera works with the Digital Trinocular Microscope With LED Illumination?
A 3.0 megapixel digital eyepiece camera, fitted to the trinocular port with the included C-mount relay lens. It connects by USB 2.0 and comes with imaging software.
Can the trinocular port be used with a screen instead of a camera?
Yes. The trinocular port can deliver the image through a digital camera or an LCD screen.
Related: Microscopes, Infinity Corrected Digital Trinocular Microscope, Coaxial Trinocular Microscope, Digital Eyepiece Camera.
For a quotation on the Digital Trinocular Microscope With LED Illumination, contact School Educational Instrument.
