All Purpose Dissecting Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10894
Quick Answer: Young explorers doing outdoor field work can use the All Purpose Dissecting Microscope, which gives an upright image at 20X under indoor or natural light, with a 74 mm working distance and room for specimens up to 40 mm tall.
Last updated: October 2026
Key Features
- 10X wide-field eyepiece with 20X magnification and a large viewing field
- Upright image using indoor or natural lighting
- Monocular head, 45° inclined with 360° rotation
- Large 14 x 11 cm stage with 60 mm black/white stage plate and mounted clips
- Working distance 74 mm; maximum specimen height 40 mm
- All-metal frame and locked-on eyepiece
Technical Specifications
| Specification | Value |
|---|---|
| Head | Monocular, 45° inclined, 360° rotation |
| Eyepiece | 10X wide-field, locked-on |
| Magnification | 20X |
| Stage | 14 x 11 cm with 60 mm black/white plate and mounted clips |
| Working distance | 74 mm |
| Maximum specimen height | 40 mm |
| Lighting | Indoor or natural light |
| Frame | All metal |
About This Product
Dissecting work needs space and an image that is the right way up, and this microscope gives both: an upright image at 20X, a 74 mm working distance and room for specimens up to 40 mm high on a large 14 x 11 cm stage. The 60 mm black/white stage plate lets the background be chosen to contrast with the specimen, and the all-metal frame suits portable use indoors or outdoors. School Educational Instrument can ship the All Purpose Dissecting Microscope to Qatar, Uganda, Japan, Indonesia, Armenia and New Zealand.
Frequently Asked Questions
How large a specimen can it hold?
Specimens up to 40 mm high fit under the objective, which has a working distance of 74 mm, on a 14 x 11 cm stage.
Why does the stage plate have black and white sides?
The 60 mm plate can be turned so its background contrasts with the specimen, light objects on black and dark ones on white.
Related: Microscopes, Senior Dissecting Microscope, Field Trip Microscope with Wooden Carrying Case, Student Stereo Microscope.
For a quotation on the All Purpose Dissecting Microscope, contact School Educational Instrument.
