Inverted Fluorescence Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10888
Quick Answer: Built around a stage for culture dishes and 96-hole plates, this inverted microscope has a Seidentopf trinocular head, infinity plan objectives from 4x to 40x and a long working distance condenser, lit by 12V 30W halogen Koehler illumination.
Last updated: October 2026
Key Features
- Seidentopf trinocular head inclined at 45°, light split 100:0 and 80:20, interpupillary distance 48 to 76 mm
- WF 10x/22 mm dioptre-adjustable eyepieces
- Infinity plan objectives 4x, 10x, 20x and 40x
- Low-position coaxial coarse and fine focusing
- Stage for 96-hole plates and a 54 mm culture dish holder
- Quickly detachable long working distance condenser
Technical Specifications
| Specification | Value |
|---|---|
| Viewing head | Seidentopf trinocular, inclined 45°, light split 100:0 and 80:20 |
| Interpupillary distance | 48 to 76 mm |
| Eyepieces | WF 10x/22 mm, dioptre adjustable |
| Objectives | Infinity plan 4x (NA 0.10, WD 18.5 mm), 10x, 20x, 40x (NA 0.75, WD 0.51 mm) |
| Focusing | Low-position coaxial coarse and fine; coarse stroke 42 mm per rotation, fine stroke 0.2 mm per rotation, minimum reading 2 µm |
| Stage | Mechanical, 210 x 241 mm; round slide diameter 118 mm |
| Plate stage | Attachable, for 96-hole plates, moving range 128 x 80 mm |
| Culture dish holder | 54 mm |
| Condenser | Long working distance, quickly detachable; working distance 72 mm with condenser, 95 mm without |
| Light source | Transmitted halogen, 12V 30W, Koehler illumination |
About This Product
Because the objectives sit below the stage, an inverted microscope looks up through the base of a dish or well plate, so cultures can be viewed without making a slide. The attachable stage takes 96-hole plates, a 54 mm culture dish holder is provided, and removing the condenser raises the working distance from 72 mm to 95 mm for extra-high culture dishes. The Seidentopf trinocular head splits light 100:0 or 80:20. School Educational Instrument can supply the Inverted Fluorescence Microscope to schools and colleges in Barbados, Uruguay, Papua New Guinea, Mozambique and Bahrain.
Frequently Asked Questions
Can the Inverted Fluorescence Microscope hold well plates?
Yes. An attachable mechanical stage takes 96-hole plates with a moving range of 128 x 80 mm, and a 54 mm culture dish holder is also provided. The stage knob can be set for left or right hand use.
Why is the condenser detachable?
The long working distance condenser gives 72 mm of working distance; taking it off raises this to 95 mm so that extra-high culture vessels fit on the stage.
