Metallurgical and Industrial Inspection Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10881
Quick Answer: For brightfield, darkfield and polarising work on opaque materials, this inspection microscope combines a reflection Kohler illuminator with a 12V/50W halogen bulb, a Siedentopf trinocular head inclined at 45° and magnification from 50x to 1000x.
Last updated: October 2026
Key Features
- Reflection Kohler illuminator with iris diaphragm and centrable field diaphragm; 12V/50W halogen, wide voltage 90-240V
- Siedentopf trinocular head, 45° inclined, interpupillary distance 54-75mm, dioptre adjustment ±5
- Light split 100% binocular, or binocular:trinocular 80%:20%
- Reversed quintuple/sextuple nosepiece with LWD infinity plan semi-APO objectives
- Double-layer mechanical stage 160×250mm, moving range 50×50mm, X-Y coaxial control
- Coaxial focus with tension control and upper limit stopper, 0.01mm per revolution; brightfield, darkfield and polarising observation
Technical Specifications
| Specification | Value |
|---|---|
| Illumination | Reflection Kohler, iris and centrable field diaphragm, 12V/50W halogen, 90-240V |
| Viewing head | Siedentopf trinocular, 45° inclined, IPD 54-75mm, dioptre ±5 |
| Light split | 100% binocular; or 80%:20% binocular:trinocular |
| Nosepiece | Reversed quintuple/sextuple |
| Objectives | LWD infinity plan semi-APO |
| Eyepiece | WF 10X high-point wide-field, FOV 22/25mm |
| Stage | Fixed stage with 3-point support; attachable double-layer mechanical stage 160×250mm, range 50×50mm |
| Focusing | Coaxial, tension control, upper limit stopper, 0.01mm per revolution |
| Observation | Brightfield, darkfield, polarising |
| Magnification | 50x-1000x |
| Filters | Blue, green; built-in slots for analyser and polariser |
About This Product
This inspection microscope lights the specimen from above with a reflection Kohler illuminator, which has an iris diaphragm, a centrable field diaphragm and a 12V/50W halogen bulb with continuously adjustable intensity. It offers brightfield, darkfield and polarising observation from 50x to 1000x, with built-in slots for the analyser and polariser and blue and green filters. The Siedentopf trinocular head is inclined at 45°, and the double-layer mechanical stage moves 50×50mm under coaxial X-Y control. Buyers in the Comoros, Côte d'Ivoire, Palestine, Morocco and Italy can send an export enquiry for the Metallurgical and Industrial Inspection Microscope.
Frequently Asked Questions
What observation modes are available?
Brightfield, darkfield and polarising observation, with blue and green filters and built-in slots for the analyser and polariser.
What power supply does it accept?
The illuminator has a wide voltage range of 90-240V and uses a 12V/50W halogen bulb with continuously adjustable intensity.
