Double Wall Autoclave With Vacuum Manufacturer,Supplier and Exporter
Product Code : SEL-A-11617
Quick Answer: Combining a double-wall design with pre- and post-vacuum, this fully automatic autoclave comes in 35, 75 and 111 litre capacities and uses a microprocessor-based PID controller with dual display for temperature and time.
Last updated: October 2026
Key Features
- Double-wall design with a heavy-duty jacket
- Pre-vacuum and post-vacuum available
- Fully automatic operation
- Microprocessor-based PID controller with dual display for temperature and time
- Reduced loading height
- 230V supply with digital control
Technical Specifications
| Specification | Value |
|---|---|
| Capacities | 35, 75 and 111 litres |
| Chamber dimension | 300 x 500 mm (35 L), 400 x 600 mm (75 L), 450 x 700 mm (111 L) |
| Power consumption | 2 kW (35 L), 6 kW (75 L and 111 L) |
| Operating pressure | 1.2 - 2.1 kg/cm2 |
| Voltage | 230V |
| Control | Digital |
| Gross weight | 139 or 147 kg (35 L), 161 or 169 kg (75 L), 249 or 257 kg (111 L) |
About This Product
Pre-vacuum and post-vacuum are what set this double-wall autoclave apart, and it runs fully automatically rather than semi-automatically. It has a heavy-duty jacket and a reduced loading height, and temperature and time are shown on a microprocessor-based PID controller with dual display. Each of the three capacities runs on 230V with digital control, drawing 2 kW for the 35 litre size and 6 kW for the larger two. School Educational Instrument can supply the Double Wall Autoclave With Vacuum to schools and colleges in Sudan, Tanzania, Serbia, New Zealand, Vanuatu and Iceland.
Frequently Asked Questions
What capacities are available?
35, 75 and 111 litres, with chamber dimensions of 300 x 500 mm, 400 x 600 mm and 450 x 700 mm. Two versions of each capacity are offered, weighing 139 or 147 kg, 161 or 169 kg, and 249 or 257 kg.
Does this autoclave have a vacuum function?
Yes. Pre-vacuum and post-vacuum are available, and operation is fully automatic with a PID controller that displays temperature and time.
What power supply does it need?
All models run on 230V. The 35 litre model draws 2 kW, and the 75 and 111 litre models draw 6 kW.
Related: Autoclaves, Semi Automatic Double Wall Autoclave, Fully Automatic Autoclave, Horizontal Steam Autoclave.
For a quotation on the Double Wall Autoclave With Vacuum, contact School Educational Instrument.
