Parting Tool Holder Manufacturer,Supplier and Exporter
Product Code : SEL-MMTM-11808
Quick Answer: Of one-piece construction, the Parting Tool Holder holds and guides a bevelled parting blade with equal clearance on both sides, and it fits either the front or the rear tool post of a lathe.
Last updated: October 2026
Key Features
- One-piece construction
- Fits front and rear tool posts
- Holds and guides a bevelled blade with equal clearance on both sides
- Three sizes, for blades of 1/2 x 3/32 in, 5/8 x 3/32 in and 3/4 x 1/8 in
- Supplied without the blade
Technical Specifications
| Specification | Value |
|---|---|
| For blade 1/2 x 3/32 in | Length 2-3/4 in, height 13/16 in, width 1/2 in, depth 1/2 in |
| For blade 5/8 x 3/32 in | Length 2-3/4 in, height 13/16 in, width 1/2 in, depth 9/16 in |
| For blade 3/4 x 1/8 in | Length 2-3/4 in, height 13/16 in, width 19/32 in, depth 11/16 in |
About This Product
Parting off cuts a finished piece free from the bar on a lathe, using a thin blade fed straight into the turning work. This holder grips and guides a bevelled blade so that clearance is equal on both sides, and because it mounts on the front or the rear tool post it can be set up to suit the lathe in use. Blades are ordered separately. School Educational Instrument can ship the Parting Tool Holder to Moldova, Zambia, Yemen, Saint Vincent and the Grenadines and Togo.
Frequently Asked Questions
Is the parting blade included?
No. The holder is supplied without the blade; it takes blades of 1/2 x 3/32 in, 5/8 x 3/32 in or 3/4 x 1/8 in, depending on the holder size chosen.
Can it be used on the rear tool post?
Yes. It can be used on both the front and the rear tool post.
Related: Metal Manufacturing Training Machine, Knurling Tool Holder, Boring Bars with Holder, Center Lathe Machine.
For a quotation on the Parting Tool Holder, contact School Educational Instrument.
