CNC Lathe System Manufacturer,Supplier and Exporter
Product Code : SEL-CTM-11630
Quick Answer: Turning up to 260 mm in diameter over the bed with 600 mm between centres, the CNC Lathe System has a 2.2 kW motor, spindle speeds of 30–4000 rpm and a 26 mm spindle bore.
Last updated: October 2026
Key Features
Turning diameter over bed 260 mm; 600 mm between centres
2.2 kW motor, 230 V, 50 Hz
Spindle speeds 30–4000 rpm; spindle bore 26 mm
X travel 130 mm, Z travel 465 mm
Rapid speed X 3000 mm/min, Z 2500 mm/min
Metric pitch 0.2–3.5 mm; inch pitch 8–56 TPI
Technical Specifications
Specification
Value
Turning diameter over bed
260 mm
Distance between centres
600 mm
X / Z travel
130 / 465 mm
Rapid speed X / Z
3000 / 2500 mm/min
Spindle bore
26 mm
Spindle speeds
30–4000 rpm
Pitch, metric
0.2–3.5 mm
Pitch, inch
8–56 TPI
Motor power
2.2 kW, 230 V, 50 Hz
Packing size
2220 x 820 x 1720 mm
About This Product
With 600 mm between centres and 465 mm of Z travel, this lathe takes longer work than a compact bench trainer, and its 26 mm spindle bore lets bar stock pass through the spindle. Pitches run from 0.2 to 3.5 mm metric and 8 to 56 TPI inch, so thread work can be taught in both systems on one machine. It runs from a 230 V, 50 Hz supply and suits CNC turning courses in college and vocational workshops.
Frequently Asked Questions
What thread pitch range does the CNC Lathe System cover?
Metric pitches from 0.2 to 3.5 mm and inch pitches from 8 to 56 TPI.
