Infinity Corrected Binocular Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10903
Quick Answer: Designed for college and laboratory teaching, the Infinity Corrected Binocular Microscope keeps tube length constant when the 50 mm to 75 mm interpupillary distance is changed, and pairs a 3W LED with an N.A. 1.25 Abbe condenser on a rack and pinion.
Last updated: October 2026
Key Features
- Binocular head, 30° inclined and 360° rotatable; tube length unchanged by interpupillary adjustment
- WF 10x/20 mm eyepieces with dioptre adjustment on the left tube
- Reversed quadruple ball-bearing nosepiece with internal click stops; objectives colour-coded, parfocal and parcentred
- Low-position coaxial coarse and fine focus on both sides, 2 µm fine graduation, tension adjustment
- 145 mm x 140 mm double-layer mechanical stage, cross travel 7.6 cm x 5.2 cm, two-slide holder
- N.A. 1.25 Abbe condenser with graduated iris diaphragm; 3W LED with intensity control
Technical Specifications
| Specification | Value |
|---|---|
| Viewing head | Binocular, 30° inclined, 360° rotatable |
| Interpupillary distance | 50 mm to 75 mm |
| Eyepieces | WF 10x/20 mm; dioptre adjustable on left tube |
| Reticule eyepiece | Optional, 0.1 mm scale (not included) |
| Nosepiece | Revolving reversed quadruple, ball bearing, internal click stops |
| Focusing | Low-position coaxial coarse and fine, both sides; coarse stroke 26 mm; fine graduation 2 µm; range 19 mm |
| Stage | 145 mm x 140 mm double-layer mechanical; travel 7.6 cm x 5.2 cm; two-slide holder |
| Condenser | N.A. 1.25 Abbe, rack and pinion height control, graduated iris diaphragm |
| Illumination | 3W LED with intensity control |
| Frame | Cast aluminium, one-piece arm and base, integrated carrying handle; antifungal treatment |
About This Product
Students sharing one instrument usually reset the eyepiece spacing for their own eyes; on this head that change does not alter tube length, so focus holds between users. The graduated scale on the condenser diaphragm shows roughly which setting suits each objective, a useful prompt when learning to balance contrast and depth of field. The cast frame with built-in handle is steady on the bench and easy to move between rooms.
Frequently Asked Questions
Does adjusting the eyepiece spacing affect focus?
No. The binocular head keeps the length of the eyepiece tubes unchanged when the interpupillary distance (50 mm to 75 mm) is adjusted, so focus is kept when users change over.
Can it be used for measurement?
An optional reticule eyepiece with 0.1 mm scales is available for measuring, but it is not included as standard.
