LCD Screen Digital Handheld Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10909
Quick Answer: Held in the hand, this digital microscope shows a magnified image on its own 3 inch LCD screen, with a 5 megapixel sensor, 10x to 300x magnification (up to 1200x digital) and photo and video capture to a MicroSD card.
Last updated: October 2026
Key Features
- Portable 3 inch LCD screen; photo and video capture with measurement
- Image sensor of 5 megapixels
- Magnification 10x to 300x, up to 1200x by digital, set by a wheel control
- Eight LEDs with light intensity control
- Manual focus range 10 mm to 50 mm
- Rechargeable lithium battery (adaptor or USB); MicroSD slot up to 32GB; TV and USB cables included
Technical Specifications
| Specification | Value |
|---|---|
| Screen | 3 inch LCD |
| Image sensor | 5 megapixels |
| Still/video capture resolution | 12M, 9M, 5M, 3M, 1.3M, VGA |
| Magnification | 10x to 300x; up to 1200x digital |
| Focus range | Manual, 10 mm to 50 mm |
| Frame rate | Max 30 f/s under 600 lux |
| Light source | 8 LED, intensity control |
| Storage | MicroSD card slot, up to 32GB SDHC |
| Outputs | TV output (cable included); USB to computer (cord included) |
| Battery | Rechargeable lithium, charged by adaptor or USB |
| Software | Portable Capture Pro with measurement |
About This Product
The image appears on a 3 inch screen rather than through an eyepiece, and the microscope is easy to set up and use in a classroom. The TV output can put the view on a monitor, the USB cord connects it to a computer, and the bundled Portable Capture Pro software adds measurement. With its rechargeable lithium battery and MicroSD storage, it can also be used away from a computer for practical work in school and college labs. School Educational Instrument can ship the LCD Screen Digital Handheld Microscope to New Zealand, Chad, Haiti, Paraguay, Zambia and the Dominican Republic.
Frequently Asked Questions
Does the LCD Screen Digital Handheld Microscope need a computer?
No. It has its own 3 inch LCD screen and saves photos and video to a MicroSD card (up to 32GB). It can also connect to a computer by the included USB cord or to a monitor by the TV cable.
What magnification does it reach?
Magnification is 10x to 300x, and digital zoom takes it up to 1200x, adjusted with a magnification wheel.
Related: Microscopes, Stand Alone LCD Screen Digital Microscope, Digital Microscope Pro, Pocket Microscope.
For a quotation on the LCD Screen Digital Handheld Microscope, contact School Educational Instrument.
