Penta Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10865
Quick Answer: The Penta Microscope is a multi-viewer microscope: one trinocular head and four binocular heads, all 360 rotatable, let five observers see the same slide at 40X-1000X standard, optionally up to 2000X, with a movable green LED pointer.
Last updated: October 2026
Key Features
- One high-transmission trinocular head plus four binocular heads, inclined and 360 rotatable
- WF 10x ultra wide-field compensating paired eyepieces (field no. 22), 5 pairs
- Magnification 40X-1000X standard, optionally up to 2000X
- Low, forward-position coaxial coarse and fine focusing on ball bearings, with tension control ring and pre-focus stopper
- Coarse focus 30mm; fine motion reading to 0.002mm
- Movable built-in green LED pointer with adjustable brightness
Technical Specifications
| Specification | Value |
|---|---|
| Observation heads | One trinocular (high transmission) plus four binocular, compensation free, 360 rotatable |
| Eyepieces | WF 10x ultra wide-field, compensating, field no. 22, 5 pairs |
| Magnification | 40X-1000X standard; optionally up to 2000X |
| Focusing | Coaxial coarse and fine, ball bearing, tension control ring, pre-focus stopper |
| Coarse focus range | 30mm |
| Fine focus reading | 0.002mm |
| Condenser | Swing-out |
| Pointer | Movable built-in green LED, brightness adjustable |
About This Product
A penta microscope lets five observers view the same slide at once, through one trinocular head and four binocular heads that are inclined and rotate through 360 degrees. The movable green LED pointer, with adjustable brightness, marks features in the shared field of view. Low, forward-position coaxial focusing on ball bearings, with a tension control ring and pre-focus stopper, gives a coarse focus of 30mm and fine motion reading to 0.002mm.
Frequently Asked Questions
How many people can view at once?
There is one trinocular head and four binocular heads, and the microscope comes with 5 pairs of WF 10x eyepieces, so five observers can view the same slide.
What is the green LED pointer for?
It is a movable, built-in pointer with adjustable brightness that appears in the field of view, so a feature can be pointed out to all viewers.
Related: Microscopes, Coaxial Trinocular Microscope, Binocular and Trinocular Head, Projection Microscope.
For a quotation on the Penta Microscope, contact School Educational Instrument.
