Coaxial Trinocular Microscope Manufacturer,Supplier and Exporter
Product Code : SEL-M-10867
Quick Answer: A single coaxial knob with four-step gear reduction controls coarse and fine focus on this coaxial trinocular microscope, which also has a rotatable inclined head, a graduated XY stage moving slides up to 50mm x 75mm and a 6 v-20 W halogen light.
Last updated: October 2026
Key Features
- Inclined trinocular head on a body rotatable through 360°
- Co-axial precision graduated mechanical stage, slide movement up to 50mm x 75mm, on a 120x 125mm base
- Abbe N.A. 1.25 condenser, rack and pinion focusable through 25 mm, with iris diaphragm and swing-out filter holder
- Single coaxial focusing knob with four-step gear reduction
- Built-in base halogen light, 6 v-20 W, with on/off switch and intensity regulator
- Plano-concave reflector set for daylight use
Technical Specifications
| Specification | Value |
|---|---|
| Head | Inclined trinocular; body rotatable through 360° |
| Mechanical stage | Co-axial, graduated, X and Y movement up to 50mm x 75mm |
| Stage base | 120x 125mm |
| Condenser | Abbe N.A. 1.25, rack and pinion focusing through 25 mm, iris diaphragm, swing-out filter holder |
| Focusing | Single coaxial knob, four-step gear reduction |
| Illumination | Built-in halogen, 6 v-20 W, on/off switch, intensity regulator, power cord and plug |
| Daylight option | Plano-concave reflector set |
About This Product
Coarse and fine focus share a single coaxial knob, worked through a four-step gear reduction system for smooth operation. The inclined trinocular head sits on a body that rotates through 360°, and the graduated coaxial mechanical stage moves the slide up to 50mm x 75mm. The Abbe condenser focuses by rack and pinion, and a plano-concave reflector set allows daylight use as well as the built-in halogen light. School Educational Instrument can ship the Coaxial Trinocular Microscope to Bhutan, Gabon, Yemen, Turkmenistan, Barbados and Brazil.
Frequently Asked Questions
How does the focusing work?
Coarse and fine focus are both worked by a single coaxial knob that uses a four-step gear reduction system.
Is there a daylight option?
Yes. Besides the built-in 6 v-20 W halogen light with its power cord and plug, a set of plano-concave reflectors is provided for daylight use.
