Block Making Machine Manufacturer,Supplier and Exporter
Product Code : SEL-WT-11498
Quick Answer: A hydraulic block making machine with 100 ton compacting pressure, it forms 4 bricks of 230 x 110 x 75 mm per stroke on PVC pallets and has a rated production capacity of 1680 bricks/hour.
Last updated: October 2026
Key Features
- Hydraulic power compacting at 100 ton pressure
- 4 bricks per pallet and per stroke; brick size 230 x 110 x 75 mm (with frog)
- 420 strokes/hour (7 strokes/min); rated capacity 1680 bricks/hour
- PVC type pallets, 600 x 300 x 25 mm
- Conveyor of 20-foot length
- Pan mixer with a 7.5 HP, 1480 rpm, 3 phase motor
Technical Specifications
| Specification | Value |
|---|---|
| System | Hydraulic power compacting |
| Hydraulic pressure | 100 ton |
| Total power required | 31.5 HP |
| Bricks per stroke | 4 |
| Brick size | 230 x 110 x 75 mm (with frog) |
| Strokes | 420 strokes/hour (7 strokes/min) |
| Production capacity | 1680 bricks/hour (rated) |
| Pallet | 600 x 300 x 25 mm, PVC type |
| Conveyor | 20-foot length |
| Pan mixer | Bottom plate 10 mm, side wall height 500 mm, side wall plate 5 mm |
| Pan mixer motor | 7.5 HP, 1480 rpm, 3 phase |
About This Product
For construction and building-materials training, the machine covers brick making at production scale: material is mixed in the pan mixer, compacted hydraulically into bricks on pallets and carried on the conveyor. Each stroke forms 4 bricks with a frog, and at 7 strokes a minute the rated output is 1680 bricks an hour. Installation planning should allow for a total power requirement of 31.5 HP.
Frequently Asked Questions
How many bricks does the machine make per hour?
Its rated production capacity is 1680 bricks/hour, from 4 bricks per stroke at 420 strokes/hour (7 strokes/min).
What size are the bricks?
230 x 110 x 75 mm, with frog, formed on PVC type pallets of 600 x 300 x 25 mm.
