Site Dumper Manufacturer,Supplier and Exporter
Product Code : SEL-WT-11499
Quick Answer: This 4x4 site dumper carries a payload of 3000 kg in a 1500 litre skip, with an articulated frame, hydraulic steering, a hydraulic tipping hopper and a 40 hp water cooled diesel engine.
Last updated: October 2026
Key Features
- Articulated frame chassis with hydraulic steering
- Hydraulic tipping hopper, skip capacity 1500 litres
- Payload capacity 3000 kg
- Heavy-duty 5+5 gearbox; 4x4 drive
- Four wheels with 12.5-16 tyres; turning radius 4.5 m
- Diesel engine, 40 hp, water cooled, 30 kW/2300 rpm
Technical Specifications
| Specification | Value |
|---|---|
| Chassis | Articulated frame |
| Steering | Hydraulic |
| Gearbox | Heavy duty, 5+5 |
| Driving | 4x4 WD |
| Bucket tipping system | Hydraulic tipping hopper |
| Tyres | Four wheels, 12.5-16 |
| Turning radius | 4.5 m |
| Payload capacity | 3000 kg |
| Skip capacity | 1500 litres |
| Weight | 2250 kg |
| Engine | Diesel, 40 hp, water cooling, 30 kW/2300 rpm |
About This Product
Site dumpers carry and tip material around a construction site, and this one gives construction trades training a working machine rather than a model. Its articulated frame, hydraulic steering and four-wheel drive are combined with a hydraulic tipping hopper and a heavy-duty 5+5 gearbox. The dumper weighs 2250 kg and turns within a 4.5 m radius. School Educational Instrument can ship the Site Dumper to South Korea, Tajikistan, Trinidad and Tobago, Australia, Bosnia and Herzegovina and Djibouti.
Frequently Asked Questions
How much can the site dumper carry?
Payload capacity is 3000 kg and skip capacity 1500 litres, emptied by a hydraulic tipping hopper.
What engine does it use?
A water cooled diesel engine of 40 hp, rated 30 kW at 2300 rpm.
Related: Workshop Tools, Concrete Mixer, Block Making Machine, Rammer.
For a quotation on the Site Dumper, contact School Educational Instrument.
