Upright Drilling Machine Manufacturer,Supplier and Exporter
Product Code : SEL-MMTM-11824
Quick Answer: Drilling holes up to 25 mm in diameter, the Upright Drilling Machine has a Morse No. 3 spindle taper, 140 mm spindle travel and spindle speeds of 100 to 2,900 rpm on a 50 Hz supply.
Last updated: October 2026
Key Features
- Maximum drilling diameter 25 mm
- Spindle travel 140 mm; Morse taper No. 3 spindle bore
- 315 mm from spindle centre to column
- Working table 315 x 415 mm; base plate working area 475 x 400 mm
- Spindle speeds 100 to 2,900 rpm (50 Hz); 0.75 or 0.55 kW motor
- 3-phase cooling pump, 12 L/min
Technical Specifications
| Specification | Value |
|---|---|
| Max. drilling diameter | 25 mm |
| Spindle centre to column | 315 mm |
| Max. spindle travel | 140 mm |
| Spindle bore taper | Morse No. 3 |
| Working table | 315 x 415 mm |
| Base plate working area | 475 x 400 mm |
| Spindle speeds (50 Hz) | 100 to 2,900 rpm |
| Motor power | 0.75 or 0.55 kW |
| Cooling pump | 3-phase; flow capacity 12 L/min; 0.04 kW |
| Power supply | 380 V, 50 Hz |
| Overall dimensions | 788 x 560 x 1,820 mm or 788 x 560 x 1,835 mm |
About This Product
An upright drilling machine carries its drilling head on a vertical column, with the work held on a table or base plate below the spindle. This one has both a 315 x 415 mm working table and a base plate with a 475 x 400 mm working area, and a 3-phase cooling pump supplies coolant at 12 L/min. It runs on a 380 V, 50 Hz supply and suits drilling practice in metal manufacturing workshops. School Educational Instrument can supply the Upright Drilling Machine to schools and colleges in Colombia, the Solomon Islands, Grenada, the Dominican Republic, Jamaica and Uganda.
Frequently Asked Questions
What is the drilling capacity?
Maximum drilling diameter is 25 mm, with 140 mm of spindle travel and a Morse No. 3 spindle taper.
What power supply does it need?
A 380 V, 50 Hz supply. At 50 Hz the spindle runs from 100 to 2,900 rpm, with a 0.75 or 0.55 kW motor.
Related: Metal Manufacturing Training Machine, Radial Drilling Machine, Universal Milling Machine, Center Lathe Machine.
For a quotation on the Upright Drilling Machine, contact School Educational Instrument.
