Table Docking or Radial Stone Masonry Saw Manufacturer,Supplier and Exporter
Product Code : SEL-WT-11504
Quick Answer: Stone and masonry units are cut on this Table Docking or Radial Stone Masonry Saw, which runs a 350 mm diamond blade cooled from a 55-litre water tank and offers a 650 mm cutting length.
Last updated: October 2026
Key Features
- 2 head positions, vertical cut 150 mm
- Table dimensions: 600 x 500 mm
- Water tank, 55 litres, for cooling the blade while cutting
- Diamond blade, 350 mm
- Cutting length 650 mm, mitre cutting 0-45°
- Motor 2 kW, 3000 rpm, 220/50/1 ph, with thermal protector
Technical Specifications
| Specification | Value |
|---|---|
| Head positions | 2 |
| Vertical cut | 150 mm |
| Table dimensions | 600 x 500 mm |
| Cutting length | 650 mm |
| Blade | Diamond, 350 mm |
| Mitre cutting | 0-45° |
| Water tank capacity | 55 litres |
| Motor | 220/50/1 ph, 2 kW, 3000 rpm |
| Protection | Thermal protector |
| Weight | 85 kg |
About This Product
Masonry practicals call for straight and angled cuts in stone units, and a table saw of this kind lets learners make them at a fixed station. Water from the tank keeps the diamond blade cool during the cut, while the 600 x 500 mm table supports the workpiece. With the head set in either of its 2 positions and mitre angles up to 45°, one machine covers both square and angled work in a vocational training workshop.
Frequently Asked Questions
How is the blade cooled?
A 55-litre water tank supplies water for cooling the blade while cutting.
What motor does the saw use?
A 2 kW motor running at 3000 rpm, rated 220/50/1 ph, fitted with a thermal protector.
Can it make angled cuts?
Yes. Mitre cutting is possible from 0 to 45°, and the cutting length is 650 mm.
