Z-80 Microcomputer Trainer Manufacturer,Supplier and Exporter
Product Code : SEL-MCE-10945
Quick Answer: Assembly programs written on a PC are downloaded to this Z-80 microcomputer trainer and run from system memory, so students see results at once; debugging works from the PC or the system keypad.
Last updated: October 2026
Key Features
- Assembly program code edited on a PC, then downloaded and executed from system memory
- Download, debug and execute via PC or the trainer keyboard
- Demo programs permanently stored in system ROM for quick system test and functional demonstration
- Power supply and all experimental peripherals built into a single unit
- Chip sets protected by an acrylic cover, with chip names printed in position
- External interface for user-defined circuits
Technical Specifications
| Specification | Value |
|---|---|
| Processor | Z-80 |
| Programming | Assembly code edited on a PC |
| Download, debug, execute | Via PC or trainer keyboard |
| Demo programs | Permanently stored in system ROM |
| Power and peripherals | Built into a single unit |
| Panel | Acrylic cover over chip sets, chip names printed |
| Expansion | External interface for user-defined circuits |
About This Product
Because the power supply and every experimental peripheral sit inside one unit, the Z-80 experiments on this trainer need no additional equipment. The acrylic top panel keeps the chips covered while still showing which chip is which, helping students relate their assembly code to the hardware. Demo programs in ROM let a lab check the system quickly before a session, and the external interface leaves room for circuits of the user's own design. School Educational Instrument can ship the Z-80 Microcomputer Trainer to Malawi, Kuwait, the United Arab Emirates, Guinea-Bissau and Kenya.
Frequently Asked Questions
Is any additional equipment needed for the experiments?
No. The power supply and all experimental peripherals are built into a single unit, so the Z-80 experiments require no additional equipment.
How are programs loaded and debugged?
Code is edited on a PC, and programs can be downloaded, debugged and executed via the PC or the trainer keyboard.
