CNC Lathe Machine Table Manufacturer,Supplier and Exporter
Product Code : SEL-CTM-11598
Quick Answer: Measuring 1000 x 780 x 565 mm and weighing 140 kg net, the CNC Lathe Machine Table offers a 200 mm swing over bed, a 4-station turret and a 500 W main motor for CNC turning practice.
Last updated: October 2026
Key Features
- Swing over bed 200 mm, swing over carriage 100 mm
- 460 mm centre distance, 100 mm bed width
- 4-station tool turret, 360 degree turret angle
- 500 W main motor, spindle 100–3000 rpm
- Travel X 150 mm, Z 250 mm
- Positioning precision 0.015 mm, repeat positioning 0.01 mm
Technical Specifications
| Specification | Value |
|---|---|
| Swing over bed | 200 mm |
| Swing over carriage | 100 mm |
| Centre distance | 460 mm |
| Bed width | 100 mm |
| X / Z axis max. travel | 150 / 250 mm |
| Tailstock travel | 50 mm |
| Tool turret | 4 station, 360 degree |
| Turret return orientation precision | 0.005 mm |
| Positioning precision | 0.015 mm |
| Repeat positioning precision | 0.01 mm |
| X/Z axis motor | 1.35 Nm |
| Max. moving speed X/Z | 2 m/min |
| Feeding speed X/Z | 500 mm/min |
| Main motor | 500 W |
| Spindle speed | 100–3000 rpm |
| Machine size (L x W x H) | 1000 x 780 x 565 mm |
| Gross / net weight | 180 / 140 kg |
About This Product
On this table lathe the X and Z slides travel at up to 2 m/min under program control, with a feeding speed of 500 mm/min, and the turret returns to position within 0.005 mm. A tailstock with 50 mm travel supports work held between centres. At 565 mm high and 140 kg net, it is a compact machine for teaching CNC turning in college and vocational workshops.
Frequently Asked Questions
What motor and spindle speed does it have?
The main motor is rated at 500 W and the spindle runs from 100 to 3000 rpm. The X and Z axis motors are 1.35 Nm.
What are the turning capacities?
Swing over bed is 200 mm, swing over carriage 100 mm and centre distance 460 mm, with 150 mm X-axis travel and 250 mm Z-axis travel.
