Hydraulic Steel Worker Manufacturer,Supplier and Exporter
Product Code : SEL-WEAWLM-11541
Quick Answer: Combining hole punching, shearing, bar cropping and notching stations, the Hydraulic Steel Worker comes with 10 punches and dies up to 38 mm and a goose-neck die holder up to 57 mm.
Last updated: October 2026
Key Features
- Quick-change punch holder with positive keyway location for shaped tools
- Universal 'goose neck' die holder up to 57 mm for punching flats, angles and channel
- Swing-away punch stripper
- Adjustable hold-down plate on the hole punching, shearing and bar cropping station
- Adjustable strokes with rules at the punch and shear end; 1 m auto cut length stop
- Tables with rules, plate guides and quick-release handles; halogen light on a magnetic base
Technical Specifications
| Specification | Value |
|---|---|
| Stations | Hole punching, shearing, bar cropping, notching |
| Die holder | Universal 'goose neck', up to 57 mm |
| Punches and dies | 10, up to 38 mm |
| Cut length stop | 1 m, automatic |
| Foot pedals | 2, hand-moveable |
| Overload protection | Hydraulic and electrical |
| Hydraulic unit | Compact, low-maintenance, located at the bottom inside the machine |
| Supplied with | Toolkit and operator instruction manual |
About This Product
Flats, angles and channel sections can all be punched, sheared or cropped on one hydraulic machine, so a fabrication workshop does not need a separate tool for each operation. Strokes are adjustable and read off rules at the punch and shear end, the 1 m auto cut length stop sets repeat lengths, and a key-switch isolates the notch station.
Frequently Asked Questions
What tooling is supplied?
10 punches and dies up to 38 mm are included, along with a toolkit and an operator instruction manual.
Which sections can be punched?
The universal 'goose neck' die holder, up to 57 mm, accommodates punching of flats, angles and channel.
How is the machine operated?
It has 2 hand-moveable foot pedals, and the compact hydraulic unit sits at the bottom inside the machine.
Related: Welding Equipment and Workshop Lab Machine, Electric Shear, Pillar Drill Machine, Tube Bending Machine.
For a quotation on the Hydraulic Steel Worker, contact School Educational Instrument.
